Project Details
- JAFZA Logistics Hub
- 24th March 2024
- Global Logistics Solutions FZE
- HVAC Systems, Ducting, AHUs, FCUs, Thermal Load Analysis
Lemos International successfully delivered a complete HVAC system for the JAFZA Logistics Hub, a state-of-the-art facility comprising four logistics blocks. The project encompassed static pressure and thermal load analysis, fabrication and installation of 10,000m² of galvanized iron (GI) ducting, and the installation of air handling units (AHUs), fan coil units (FCUs), inline fans, and SMACNA Class A insulation. Our team completed the project within three months, ensuring optimal climate control and energy efficiency across all logistics blocks.
Our scope of work included:
- Thermal Load Analysis: Conducted detailed thermal load calculations to determine cooling requirements for each logistics block.
- Static Pressure Analysis: Performed static pressure analysis to design an efficient ducting system that minimized energy losses.
- Duct Fabrication & Installation: Fabricated and installed 10,000m² of GI ducting, adhering to SMACNA standards for durability and performance.
- HVAC Equipment Installation: Installed AHUs, FCUs, inline fans, and other HVAC components to ensure consistent airflow and temperature regulation.
- Insulation Application: Applied SMACNA Class A insulation to ducting systems to prevent heat loss and condensation.
- Testing, Adjusting, and Balancing (TAB): Conducted TAB to verify system performance and ensure compliance with design specifications.
The project was executed with meticulous attention to detail, adhering to international standards and delivering a reliable, efficient, and sustainable HVAC solution for the logistics hub.
Key Features of the Project
Comprehensive Thermal Load Analysis
- Conducted detailed thermal load calculations to determine cooling requirements for each logistics block, ensuring optimal HVAC system sizing and performance.
- Factored in variables such as building orientation, occupancy levels, and equipment heat loads to achieve precise results.
Static Pressure Optimization
- Performed static pressure analysis to design a ducting system that minimized resistance and energy consumption while maintaining consistent airflow.
- Utilized computational fluid dynamics (CFD) simulations to validate duct design and eliminate potential bottlenecks.
High-Quality Duct Fabrication & Installation
- Fabricated 10,000m² of GI ducting in-house using advanced machinery to ensure precision and durability.
- Installed ducting systems with seamless joints and secure connections to prevent air leaks and ensure long-term reliability.
Advanced HVAC Equipment Integration
- Installed AHUs, FCUs, and inline fans strategically to optimize airflow distribution and temperature regulation across all logistics blocks.
- Integrated smart controls for remote monitoring and adjustment of HVAC parameters, enhancing operational efficiency.
SMACNA Class A Insulation
- Applied SMACNA Class A insulation to all ducting systems, ensuring superior thermal performance and condensation prevention.
- Conducted visual inspections and thermal imaging tests to verify insulation integrity.
Rigorous Testing, Adjusting, and Balancing (TAB)
- Conducted TAB procedures to verify airflow rates, temperature differentials, and system balance, ensuring compliance with design specifications.
- Documented TAB reports meticulously, providing traceability and assurance of system performance.
Challenge 1: Fabricating and Installing 10,000m² of Ducting
Handling such a large volume of ducting required careful planning to avoid delays and ensure quality.
Solution:
We pre-fabricated ducting components in our workshop using automated machinery, ensuring precision and consistency. On-site installation was executed in phases to minimize disruptions and maintain progress.
Challenge 2: Ensuring Consistent Airflow Across Large Spaces
Achieving uniform airflow in expansive logistics blocks posed significant challenges due to varying thermal loads and structural layouts.
Solution:
Our team conducted CFD simulations to design duct layouts that ensured balanced airflow distribution. Adjustable dampers were installed to fine-tune airflow during commissioning.
Challenge 3: Meeting Tight Deadlines
Completing the project within three months required efficient resource allocation and execution.
Solution:
We implemented extended shifts and deployed additional manpower where necessary. Daily progress reviews ensured that tasks were completed on schedule without compromising quality.
Challenge 4: Verifying System Performance via TAB
Conducting TAB for a large-scale HVAC system required rigorous testing and documentation to ensure compliance with design specifications.
Solution:
We employed certified TAB technicians equipped with advanced tools to measure airflow rates, temperature differentials, and system balance. Test results were documented meticulously and cross-verified for accuracy.
Outcome & Client Satisfaction
The successful completion of the JAFZA Logistics Hub – Ducting & HVAC Works project highlights Lemos International’s expertise in delivering large-scale HVAC solutions under challenging conditions. Key achievements include:
- On-Time Delivery: The project was commissioned within three months, allowing Global Logistics Solutions FZE to commence operations seamlessly.
- Energy Efficiency: The optimized ducting system and advanced HVAC equipment ensured minimal energy consumption while maintaining optimal climate control.
- Verified Performance: Rigorous TAB procedures validated system performance, ensuring compliance with design specifications and client expectations.
- Client Satisfaction: Global Logistics Solutions FZE expressed immense satisfaction with the outcome, praising our technical expertise, proactive approach, and ability to deliver high-quality results within tight deadlines.
